by using inBox is possible to control other devices with µWiFi technology: doors, roller shutters, lighting and other electric devices.
inBox gives the complete freedom for the interior design… it works with every mono-stable push-button.
the installation of a new push-button never was so simple – no chasing walls, no renovantions, can be added a new wall push-button for the lighting, push-button to open the roller shutters or gate – not only in the wall but also in the table
.. even in the shower ( because the fact that to work this device needs only a small 3V battery), it is completely safe also in places where traditional 230V switches are dangerous.
| Supply voltage: | 3V (CR123A battery) |
|---|---|
| Inputs number: | 4 |
| Inputs type: | logical, to GND |
| Galvanic isolation: | No |
| Housing: | made of polyurethane composition not containing halogens, self-extinguishing for thermal class B (130 °C) |
| Protection Rating: | IP20 |
| Dimensions: | 45 x 35 x 23 mm |
| Mounting: | in the flush-mounted box, on the lamp housing, directly connected to the LED strip, e.g. furniture |
| Protection: | reverse polarity, ESD |
| Transmission: | bi-directional, encrypted |
| Transmission frequency: | 2.4GHz |
| Communication standard: | μWiFi, compatible with WiFi |
| Communication mode: | low energy connection to other wBox modules |
| Range: | up to 100 m in open spaces, up to 40 m. in buildings (depending on the construction and terrain) |
| Number of connected devices / channel: | 7 |
| Encryption: | set of 512-bit keys, with use of elliptic curves and key negotiation for each transmission |
